Product overview Safety nets, various applications
Barrier net ø 6 mm made of polypropylene, mesh size: 100 mm - custom made
Article number
2500-100
Bending strength & abrasion resistance
good
Customs tariff number
5608 19 30
Mesh
diamond
Execution
edged all round with nylon rope
Size
any size
Material diameter
6 mm
Mesh size
100mm
Finish
antistatic
Material
high tenacity polypropylene, knotless
Unit Price per m²
€ 23.35
Barrier net ø 6 mm made of polypropylene, mesh size: 50 mm - custom made
Article number
2510-050
Bending strength & abrasion resistance
good
Customs tariff number
5608 19 30
Mesh
diamond
Execution
edged all round with nylon rope
Size
any size
Material diameter
6 mm
Mesh size
50 mm
Finish
antistatic
Material
high tenacity polypropylene, knotless
Unit Price per m²
€ 25.50
Safety net ø 5 mm (flame-retardant) made of polypropylene, mesh size: 45 mm - custom made
Article number
1903F045
Size
any size
Material
high tenacity polypropylene, knotless
Material diameter
5 mm
Mesh size
45 mm
Mesh
square
Finish
flame retardant
Edge Execution
reinforced selvedge cord of approx. 9 mm, with edged rope (white, ø 12 mm)
Mesh breaking strength
3.20 kN
Energy absorption
9.0 kJ
Tensile Strength of Edged Rope
30 kN
Standards and Rules
BG regulation no. 179, DGUV standard 101-011, EN 1263-1, DIN EN 13501-1 (flame-retarding, classification B-s1 d2), DIN 4102 (B1, flame-retarding, melt dripping)
Certificate
GS verification certificate 18100010, MPA-Bau certification report P-NDS04-851, Oeko-Tex® certificate 12.0.02466 (Standard 100)
Net class
B1
Safety net system
S (rope-edged safety net)
Regular Inspection Interval
12 months
Number of test meshes
3 pieces
Continuous operating temperature
-40 to +80 °C
Melting point
165 °C
Bending strength & abrasion resistance
good
Weather-Resistance
good
UV-Resistance
300 kly
Tensile strength after two years of climatic influences
90%
Customs tariff number
5608 19 30
Weight per m²
520 g/m²
Unit Price per m²
€ 18.10
Safety net ø 5 mm (flame-retardant) made of polypropylene, mesh size: 60 mm - custom made
Article number
1903F060
Size
any size
Material
high tenacity polypropylene, knotless
Material diameter
5 mm
Mesh size
60 mm
Mesh
square
Finish
flame retardant
Edge Execution
umlaufende Abschlusskante ca. 9 mm, mit Randseil (weiß, ø 12 mm)
Mesh breaking strength
3.20 kN
Energy absorption
6.1 kJ
Tensile Strength of Edged Rope
30 kN
Standards and Rules
BG regulation no. 179, DGUV standard 101-011, EN 1263-1, DIN EN 13501-1 (flame-retarding, classification B-s1 d2), DIN 4102 (B1, flame-retarding, melt dripping)
Certificate
GS verification certificate 18100012, MPA-Bau certification report P-NDS04-851, Oeko-Tex® certificate 12.0.02466 (Standard 100)
Net class
A1
Safety net system
S (rope-edged safety net)
Regular Inspection Interval
12 months
Number of test meshes
3 pieces
Continuous operating temperature
-40 to +80 °C
Melting point
165 °C
Bending strength & abrasion resistance
good
Weather-Resistance
good
UV-Resistance
300 kly
Tensile strength after two years of climatic influences
90%
Customs tariff number
5608 19 30
Weight per m²
410 g/m²
Unit Price per m²
€ 16.75
Safety net ø 5 mm (flame-retardant) made of polypropylene, mesh size: 100 mm - custom made
Article number
1903F100
Size
any size
Material
high tenacity polypropylene, knotless
Material diameter
5 mm
Mesh size
100 mm
Mesh
square
Finish
flame retardant
Edge Execution
reinforced selvedge cord of approx. 9 mm, with edged rope (white, ø 12 mm)
Mesh breaking strength
3.20 kN
Energy absorption
4.8 kJ
Tensile Strength of Edged Rope
30 kN
Standards and Rules
BG regulation no. 179, DGUV standard 101-011, EN 1263-1, DIN 4102 (B1, flame-retarding, non-flaming dripping)
Certificate
GS verification certificate 18100013, MPA-Bau certification report P-NDS04-851, Oeko-Tex® certificate 12.0.02466 (Standard 100)
Net class
A2
Safety net system
S (rope-edged safety net)
Regular Inspection Interval
12 months
Number of test meshes
3 pieces
Continuous operating temperature
-40 to +80 °C
Melting point
165 °C
Bending strength & abrasion resistance
good
Weather-Resistance
good
UV-Resistance
300 kly
Tensile strength after two years of climatic influences
90%
Customs tariff number
5608 19 30
Weight per m²
300 g/m²
Unit Price per m²
€ 9.80
Safety net made of polypropylene, ø 4 mm, mesh size 100 mm - custom made
Article number
2002-100
Bending strength & abrasion resistance
good
Customs tariff number
5608 19 30
Execution
edged all round with rope and thimbles
Material
high tenacity polypropylene, knotless
Mesh
square
Size
any size
Material diameter
4 mm
Mesh size
100mm
Unit Price per m²
€ 7.90
Safety Net per m² with Thimbles, Ø 5 mm, Mesh: 100 mm
Article number
2003-100
Mesh
square
Size
any size
Material
high tenacity polypropylene, knotless
Material diameter
5 mm
Mesh size
100 mm
Execution
edged all round with rope and thimbles
Mesh breaking strength
3.20 kN
Energy absorption
4.8 kJ
Tensile Strength of Edged Rope
30 kN
Weight per m²
275 g/m²
Standards and Rules
BG regulation no. 179, EN 1263-1
Certificate
GS verification certificate 18100013, Oeko-Tex® certificate 12.0.02466 (Standard 100)
Net class
A2
Safety net system
S (rope-edged safety net)
Regular Inspection Interval
12 months
Number of test meshes
3 pcs.
Continuous operating temperature
-40 to +80 °C
Melting point
165 °C
Bending strength & abrasion resistance
good
Weather-Resistance
good
UV-Resistance
300 kly
Tensile strength after two years of climatic influences
90%
Customs tariff number
5608 19 30
Unit Price per m²
€ 9.10
Safety net made of polypropylene, ø 5 mm, mesh size 300 mm - custom made
Article number
2003-300
Bending strength & abrasion resistance
good
Customs tariff number
5608 19 30
Mesh
square
Size
any size
Material
high tenacity polypropylene, knotless
Material diameter
5 mm
Mesh size
300 mm
Execution
edged all round with rope and thimbles
Unit Price per m²
€ 7.00
Huck Safety Nets can be used for various applications, as for example for transporting loads, to secure pallet racks or for overhead cable constructions. Every single net matches the high quality of a Huck safety net.
